Specs
Frequency Response: 20Hz-20Khz, -0.1db, 2Hz-800KHz, -3dB
Maximum Output: 10V RMS into 10K ohms
THD: Less than 0.0008%, 20Hz-20KHz, at 2V RMS in/out, pots centered, active stage enabled, less than 0.005% at any potentiometer setting
IMD: Less than 0.001%, CCIF
SNR: Greater than 114db, unweighted, referenced to 2V RMS
Crosstalk: -80dB, 20Hz-20KHz
Output Impedance: 75 ohms
Input Impedance: 47K ohms
Bands: 20Hz, 400Hz, 2kHz, 8kHz
Adjustment: +/-12dB at 20Hz and 8kHz, +/-6dB at 400Hz and 2kHz
Topology: fully discrete, all-bipolar, symmetrical current-feedback design with matched parts throughout, driver stage, DC coupled, and DC servo
Filtering: capacitor-gyrator for 20Hz, capacitor-inductor (LC) for all other bands
Power Supply: “Wall wart” style 16VAC transformer, regulated +/- 15V rails
Power Consumption: 4W
Size: 12.7 x 8.9 x 3.18 cm
Weight: 0.45 kgs
